12 Seats Stainless Steel Rectangle Double Stoves Upper Fume Exhaustion Electromagnetic Electric Teppanyaki Grill Table

Teppanyaki Grill Structure of 12 Seats Stainless Steel Rectangle Double Stoves Upper Fume Exhaustion Electromagnetic Electric Teppanyaki Grill Table

A piece of upper fume exhaustion double stoves teppanyaki equipment consists of teppanyaki machine body, and table decoration if customers need them.

The whole cooking plate is made of special alloy steel of 20mm thickness to avoid deformation and discoloration.The whole equipment is designed integrated to avoid further assembly or disassembly.
Non-standard equipment can be customized according to customers' requirement.

Interior Structure
Heating System:
Electric heating system: Electromagnetic plate. The temperature is controlled by temperature controller, and the main heating area is 450*400mm. Double stoves Teppanyaki Grill Table has 2 this heating areas.

Amazing Craftsmanship for12 Seats Stainless Steel Rectangle Double Stoves Upper Fume Exhaustion Electromagnetic Electric Teppanyaki Grill Table

Plate Leveling
1. Remove the steel slag and burrs during cutting.
2. Leveling the plate until the evenness is no more than 0.5mm within an area of 300mm2.

Machine Processing
1. The flat plates will be planned and shaped by a planner leaving 0.3mm allowance for grinding by a grinder.
2. The non-flat plates will be cut and planned first, leaving 0.3mm allowance for grinding by a grinding wheel.
3. The processing smoothness requirement is RA0.8.

Plate Installation
1. Install according to the technical requirements in the drawing, and the parts with marks of tolerance dimensions must be left with corresponding welding shrinkage allowance to ensure the sizes after welding are within the tolerance.
2. The welding must be full penetration, and the welded surface must be smooth without solder faults, solder skips, slag inclusion, gas holes, cracks or undercut.
3. Correction after the welding temperature is reduced to make the plate evenness less than 0.2mm within 500mm², and the straightness of each edge less than 0.2mm within 500mm².

Plate Polishing
1. Grinding the uneven weld bead then polish and shape carefully. The connecting part of the plate and trim strip must be smooth without sinking.
2. Fine grinding with fine wheel with processing requirement of the smoothness RA0.8.
3. Fine polishing of the whole plate with processing requirement of the smoothness RA0.4.

Technical Parameters for 12 Seats Stainless Steel Rectangle Double Stoves Upper Fume Exhaustion Electromagnetic Electric Teppanyaki Grill Table:
