Electromagnetic Heating Rectangle Teppanyaki Grill Table With Seven Seats

Product Details

Place of Origin: Shanghai, China

Brand Name: GREENARK

Certification: CE, CSA

Model Number: CL-C7

Payment & Shipping Terms

Minimum Order Quantity: 1set

Price: Negotiable

Packaging Details: Standard Exporting Wooden Case

Delivery Time: Within 15 to 25 Work Days

Payment Terms: T/T, L/C, West Union

Supply Ability: 500 units per month

Get Best Price
Contact Now
Specifications
High Light:

teppanyaki table grill

,

built in teppanyaki grill

Material:
Stainless Steel 304 & Alloy Steel
Heating:
Electromagnetic ( Induction )
Parameter:
380V/50HZ/8KW
Dimensions:
1200*850*800mm
Ventilation:
Fume Extracted Down Through The Equipment
Exhaustion:
Built-in Air Blower
Purification:
Built-in Electrostatic Fume Purifier
Material:
Stainless Steel 304 & Alloy Steel
Heating:
Electromagnetic ( Induction )
Parameter:
380V/50HZ/8KW
Dimensions:
1200*850*800mm
Ventilation:
Fume Extracted Down Through The Equipment
Exhaustion:
Built-in Air Blower
Purification:
Built-in Electrostatic Fume Purifier
Description
Electromagnetic Heating Rectangle Teppanyaki Grill Table With Seven Seats



GREENARK 7 Seats Rectangle electromagnetic heating Teppanyaki Grill Equipment is one of Chuanglv's classical products.  Why do 85% customers in China choose this model of Teppanyaki Grill Equipment?



Please firstly have a look at the craftmanship detail of our Teppanyaki Grill Equipment:



Electromagnetic Heating Rectangle Teppanyaki Grill Table With Seven Seats 0



Secondly, please check the advantages of this Seven Seats Rectangle Teppanyaki Grill Equipment:



A. Grill body made of German 304 stainless steel, heating plate made of special alloy steel with thickness of 20mm, one-piece unibody, no deformation or discoloration after long time use.



B. Operation panel, waste container and filter made of 1.0mm stainless steel, and the air inlet made of 1.5mm mirror surface stainless steel.



C. Amazing craftmanship of cutting, bending and polishing by imported intelligent processing machines.



D. Electromagnetic (Induction) Teppanyaki:



1) The only manufacturer in China who specially designes and assembles electromagnetic plate and motor for teppanyaki equipment;



2) German Infinon power module and NEC rectifier;



3) The circuit board material is in conformity with UL and Rohs certification, the master chip is with imported 32's DSP digital processing unit, and the 6-layered heat resistant insulative material makes the motor work for a much longer time;



4) Electromagnetic radiation is only 18k-35k, which is much lower than the European standard limit of 100k.



E. Certification: ISO 9001-2008; CE; CSA; UL certification is in process.



Comparison Between Four Heating Methods
Heating Method Electromagnetic/Induction Electric Tube Heaters LPG Pipeline Natural Gas
Regular Parameter 380v/50hz/8kw/3-Phase 380v/50hz/8kw/3-Phase 8kw(≈18mj/m³) 8kw(≈33mj/m³)
Rated Pressure / / 2800pa±500pa 2000pa±10%
Consumption 8kwh 8kwh 0.29m³/0.6kgs/h 0.8m³/h
Cooking Area 450*400mm 600*400mm φ500mm φ500mm
Enlarged Cooking Area 600*400mm 700*400mm / /
Temp Rising 6min to Reach 260℃ 15-18min to Reach 260℃ 15min to Reach 260℃ 15min to Reach 260℃
Temp Difference Between Real Temp & Indicator Temp ±1℃ ±20℃ ±20℃ ±20℃
Homeothermy Good Normal Normal Normal
Adventage Safe, high efficiency, easy operation and temperature control; electromagnetic radiation only 18-30k Safe, high efficiency, easy operation; low temperature return, takes about 2-3min to get the set temperature after cooking a dish Thermostat control, automatic electronic ignition device, automatic flame failure protection device Thermostat control, automatic electronic ignition device, automatic flame failure protection device
Electromagnetic Heating Rectangle Teppanyaki Grill Table With Seven Seats 1 Shanghai Chuanglv Hotel Equipment Co., Ltd No.253, Xuanchun Road, Sanzao Industrial Park, Pudong, Shanghai, China, 201314 Tel: 0086 21 68286653 Fax: 0086 21 58033433 Website: tiebanshao.en.alibaba.com www.teppanyakigrilltable.com



Cooking Plate



Special alloy steel of 20mm thickness made in one unibody mould to avoid deformation or color change.





Air Inlet



Exclusive arch design to absorb the smoke on the grill top faster and better.





Removable Air Pipe



Between the air inlet and interior tank, for easier disassembly and cleaning.





Waste Container



Sunk pull handle and plate is impact molded , and all corners are rounded to ensure good looking, easy cleaning and long shelf-life.





Air Valve Device



Three levels of open, semi-open, close function for cooking performance with flame.





Electricity Control Box



Individual electric box to hold dangerous electrical components such as leakage protection device and overload protection device.





Front Air Supply Device



A line of air blowing holes opposite to the air inlet blowing the smoke towards exhaust efficiency.





Operation Control Panel



The individual sunk panel is impact molded for good looking and easy maintenance.





Removable Double Fume Filters



Between the air inlet and interior tank for easy cleaning and inspection.





Fume Exhaust and Heat Dissipation Device



Electrostatic fume purifier to remove fume particles and cooling fan to lower the temperature  to lengthen the equipment safety and shelf-life.





Low Noise  Blower



For assisting the air exhaust of the general duct or individual straight pipe within 3 meters to better remove the fume and smoke on the cooking plate.
