• Down Fume Exhaustion Gas or LPG Heating Japanese Teppanyaki Grill Table 11 Seats
Down Fume Exhaustion Gas or LPG Heating Japanese Teppanyaki Grill Table 11 Seats

Down Fume Exhaustion Gas or LPG Heating Japanese Teppanyaki Grill Table 11 Seats

Product Details:

Place of Origin: Shanghai, China
Brand Name: GREENARK
Certification: CE, CSA, ISO9001
Model Number: CL-S11

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: Negotiable
Packaging Details: Standard Exporting Wooden Case
Delivery Time: Within 15 to 25 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500 units per month
Get Best Price Contact Now

Detail Information

Product Name: 11 Seats Stainless Steel Fan Shape Down Fume Exhaustion Gas Or LPG Heating Japanese Teppanyaki Grill Table Material: Stainless Steel And Alloy Steel
Rated Power: 8KW Rated Pressure: LPG: 2800pa; Pipeline Nat Gas: 2000pa
Air Consumption: LPG: 0.29m³/h Or 0.6kgs/h; Pipeline Nat Gas: 0.8m³/h Grill Dimension: 2300*990*800mm
High Light:

japanese hibachi grill

,

japanese hibachi table

Product Description

11 Seats Stainless Steel Fan Shape Down Fume Exhaustion Gas or LPG Heating Japanese Teppanyaki Grill Table





Teppanyaki Grill Structure


A piece of teppanyaki equipment consists of machine body, table decoration, fume purifier and air blower.
The cooking plate is made of special alloy steel of 20mm thickness to avoid deformation and discoloration.
The whole equipment is designed integrated to avoid further assembly or disassembly.
Non-standard equipment can be customized according to customers' requirement.





Interior Structure



Heating System:



Gas or LPG heating system:

Casting Iron gas or LPG burner in diameter of 9 inches. The temperature is controlled by the gas or LPG switch, and the main heating area is in diameter of 500mm.



Heat Preservation System:

The area around the main heating area is for warm keeping, and the temperature has to be within 100℃ to avoid hurting the customers or chefs.



Fire Prevention System:

To prevent fire getting into the exhaust duct and causing dangers.



Waste Gas Treatment System:

To exhaust and ventilate the waste gas in the equipment.





Double Fume Filters:
The fume filter and oil collecting drawer can make the oil directly drop into the collecting drawer and not get into the air duct...


Built-in Air Blower
Equipped according to the functions of the teppanyaki equipment. Heat preservative, low noise, 380v/0.25kw.


Electrostatic Fume Purifier Device
Customized according to the equipment functions and sizes (220v/0.25kw)
Remove fume particles larger than diameter0.1μm with efficiency of 93-97.2%
Designed with high and low voltage dust collecting polar plate separation technology for easy cleaning
Advanced point discharging technology
Power-off protection device in case of output disorder





11 Seats Stainless Steel Fan Shape Down Fume Exhaustion Gas or LPG Heating Japanese Teppanyaki Grill Table Technical Parameter:

Product Name 11 Seat Fan Shape Gas Teppnayaki Grill with Exhaustion & Purification System
Heating LPG/Pipeline Natural Gas
Material Stainless Steel 304/ Alloy Steel
Rated Heat Power 8KW
Rated Pressure LPG: 2800pa; Pipeline Nat Gas: 2000pa
Cooking Area diameter 500mm
Capacity 11 Seats
Grill Dimension 2300*990*800mm
Dimension with Table Top 3602*2001*800mm
Air Consumption LPG: 0.29m³/h or 0.6kgs/h; Pipeline Nat Gas: 0.8m³/h
Exhaustion Built-in air blower (380V/0.25KW or 220V/0.51KW)
Purification Built-in electrostatic fume purifier (220V/0.25KW)
Table Decoration Regular design/customization
Application Outdoor barbecue, restaurant, hotel, food plazza, buffet car, etc.
Cookable Food Beef, mutton, chicken, fish, shellfish, vegetable, rice, noodle, etc.
Lead Time 10-15 working days
Packaging Standard Shipping Wooden Case
Brand GREENARK/OEM
Certification

ISO9001-2008, CE & CSA available; UL in progress
