Product Details
Place of Origin: Shanghai, China
Brand Name: GREENARK
Certification: CE, CSA
Model Number: CL-Y12
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Standard Exporting Wooden Case
Delivery Time: Within 15 to 25 Work Days
Payment Terms: T/T, L/C, West Union
Supply Ability: 500 units per month
Material: |
Stainless Steel 304 & Alloy Steel |
Dimensions: |
R1000*800mm |
Dimensions With Table: |
R1500*800MM |
Cooking Area: |
φ500mm |
Heat Power: |
8KW |
Exhaustion: |
Optional Built-in Air Blower (380V/0.25KW) |
Purification: |
Optional Built-in Electrostatic Fume Purifier (220V/0.25KW) |
Gas Consumption: |
LPG: 0.29m³/h Or 0.6kgs/h; Pipeline Nat Gas: 0.8m³/h |
Material: |
Stainless Steel 304 & Alloy Steel |
Dimensions: |
R1000*800mm |
Dimensions With Table: |
R1500*800MM |
Cooking Area: |
φ500mm |
Heat Power: |
8KW |
Exhaustion: |
Optional Built-in Air Blower (380V/0.25KW) |
Purification: |
Optional Built-in Electrostatic Fume Purifier (220V/0.25KW) |
Gas Consumption: |
LPG: 0.29m³/h Or 0.6kgs/h; Pipeline Nat Gas: 0.8m³/h |
Fish Shellfish Vegetable Hibachi Japanese Grill Table With Fume Precipitator
| Product Name | 12 Seat Circle Gas Teppnayaki Grill Table with Precipitator |
| Heating | LPG/Pipeline Natural Gas |
| Material | Stainless Steel 304/ Alloy Steel |
| Rated Heat Power | 8KW |
| Cooking Area | φ500mm |
| Capacity | 12 Seats |
| Grill Dimension | R1000*800mm |
| Dimension with Table Top | R1500*800mm |
| Rated Air Pressure | LPG: 2800pa; Pipeline Nat Gas: 2000pa |
| Air Consumption | LPG: 0.29m³/h or 0.6kgs/h; Pipeline Nat Gas: 0.8m³/h |
| Exhaustion | None |
| Purification | Built-in electrostatic fume precipitator (220V/0.25KW) |
| Table Decoration | Regular design/customization |
| Application | Outdoor barbecue, restaurant, hotel, food plazza, buffet car, etc. |
| Cookable Food | Beef, mutton, chicken, fish, shellfish, vegetable, rice, noodle, etc. |
| Lead Time | 15-30 working days |
| Packaging | Standard Shipping Wooden Case |
| Brand | GREENARK/OEM |
| Certification | ISO9001-2008, CE available; CSA, UL in progress |
Why choose Chuanglv GREENARK Teppanyaki?
A. Operation panel, waste container and filter made of 1.0mm stainless steel, and the air inlet made of 1.5mm mirror surface stainless steel.
B. Electromagnetic(Induction) Teppanyaki:
1) The only manufacturer in China who specially designed and assembles electromagnetic plate and motor for teppanyaki equipment;
2) German Infinon power module and NEC rectifier;
3) The circuit board material is in conformity with UL and ROHS certification, the master chip is with imported 32's DSP digital processing unit, and the 6-layered heat resistant insulative material makes the motor work for a much longer time;
4) Electromagnetic radiation is only 18k-35k, which is much lower than the European standard limit of 100k.
C. Built-in Air Blower: High temperature resistant; low noise.
D. Certification: ISO 9001-2008; CE; CSA & UL certification in progress.
| Comparison Of Three Heating Methods | |||
| Heating Method | Electromagnetic/Induction | LPG | Pipeline Natural Gas |
| Regular Parameter | 380v/50hz/8kw/3-Phase | 8kw(≈18mj/m³) | 8kw(≈33mj/m³) |
| Rated Pressure | / | 2800pa±500pa | 2000pa±10% |
| Consumption | 8kwh | 0.29m³/0.6kgs/h | 0.8m³/h |
| Cooking Area | 450*400mm | φ500mm | φ500mm |
| Enlarged Cooking Area | 600*400mm | / | / |
| Temp Rising | 6min to Reach 260℃ | 15min to Reach 260℃ | 15min to Reach 260℃ |
| Temp Difference Between Real Temp & Indicator Temp | ±1℃ | ±20℃ | ±20℃ |
| Homeothermy | Good | Poor | Poor |
| Adventage | Safe, high efficiency, easy operation and temperature control; electromagnetic radiation only 18-30k | Thermostat control, automatic electronic ignition device, automatic flame failure protection device | Thermostat control, automatic electronic ignition device, automatic flame failure protection device |
