Product Details
Place of Origin: Shanghai, China
Brand Name: GREENARK
Certification: CE, CSA
Model Number: CL
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Standard Exporting Wooden Case
Delivery Time: Within 15 to 25 Work Days
Payment Terms: T/T, L/C, West Union
Supply Ability: 500 units per month
Material: |
Stainless Steel 304 & Alloy Steel |
Heating: |
LPG |
Dimensions: |
1120*720*790mm |
Heat Power: |
8KW |
Rated Pressure: |
2800pa |
Gas Consumption: |
0.29m³/h Or 0.6kgs/h |
Exhaustion: |
Built-in Air Blower (380V/0.25KW) |
Purification: |
Built-in Electrostatic Fume Purifier (220V/0.25KW) |
Material: |
Stainless Steel 304 & Alloy Steel |
Heating: |
LPG |
Dimensions: |
1120*720*790mm |
Heat Power: |
8KW |
Rated Pressure: |
2800pa |
Gas Consumption: |
0.29m³/h Or 0.6kgs/h |
Exhaustion: |
Built-in Air Blower (380V/0.25KW) |
Purification: |
Built-in Electrostatic Fume Purifier (220V/0.25KW) |
Custom BBQ Mobile Kitchen Teppanyaki Grill With Exhaust / Fume Precipitator
| Product Name | Gas MobileTeppanyaki Grill Full Configuration |
| Material | Stainless Steel 304/ Alloy Steel |
| Heating | LPG |
| Rated Pressure | 2800pa |
| Heat Power | 8kw |
| Gas Consumption | 0.29m³/h or 0.6kgs/h |
| Cooking Area | φ500mm |
| Grill Dimension | 1120*720*790mm |
| Ventilation | Fume extracted down through the equipment |
| Exhaustion | Built-in air blower (380V/0.25KW or 220V/0.51KW) |
| Purification | Built-in electrostatic fume purifier (220V/0.25KW) |
| Table Decoration | No decoration/customized |
| Application | Outdoor barbecue, restaurant, hotel, food plazza, buffet car, etc. |
| Cookable Food | Beef, mutton, chicken, fish, shellfish, vegetable, rice, noodle, etc. |
| Lead Time | 15 work days |
| Packaging | Standard Shipping Wooden Case |
| Brand | GREENARK/OEM |
| Certification | ISO9001-2008, CE available; CSA, UL in progress |
Why choose Chuanglv GREENARK Teppanyaki?
♣ Operation panel, waste container and filter made of 1.0mm stainless steal, and the air inlet made of 1.5mm mirror surface stainless steal.
♣ Amazing craft of cutting, bending and polishing by imported intelligent processing machines.
♣ Gas Teppanyaki:
1) Gas consumption: LPG 0.29m3/h (0.6kgs), pipeline gas 0.8m3/h.
2) Thermostat control, automatic electronic ignition device, automatic flame failure protection device.
♣ Built-in Air Blower: High temperature resistant; low noise.
♣ Built-in Taiwan Electrostatic Fume Purifier:
1) Absorbing fume particles with diameter of over 0.1 um (diameter) with processing efficiency of 93%-97%;
2) High and low voltage dust collecting plate separation technology, easy for cleaning;
3) Advanced point discharging technology;
4) Power-off protection device for output disorder.
♣ Certification: ISO 9001-2008; CE; CSA & UL certification in process.
| Comparison Of Three Heating Methods | |||
| Heating Method | Electromagnetic/Induction | LPG | Pipeline Natural Gas |
| Regular Parameter | 380v/50hz/8kw/3-Phase | 8kw(≈18mj/m³) | 8kw(≈33mj/m³) |
| Rated Pressure | / | 2800pa±500pa | 2000pa±10% |
| Consumption | 8kwh | 0.29m³/0.6kgs/h | 0.8m³/h |
| Cooking Area | 450*400mm | φ500mm | φ500mm |
| Enlarged Cooking Area | 600*400mm | / | / |
| Temp Rising | 6min to Reach 260℃ | 15min to Reach 260℃ | 15min to Reach 260℃ |
| Temp Difference Between Real Temp & Indicator Temp | ±1℃ | ±20℃ | ±20℃ |
| Homeothermy | Good | Poor | Poor |
| Adventage | Safe, high efficiency, easy operation and temperature control; electromagnetic radiation only 18-30k | Thermostat control, automatic electronic ignition device, automatic flame failure protection device | Thermostat control, automatic electronic ignition device, automatic flame failure protection device |
