Bridge Shape Upper or Down Fume Exhaustion Teppanyaki Grill Table With 11 Seats

Product Details

Place of Origin: Shanghai, China

Brand Name: GREENARK

Certification: ISO9001;CE;CSA

Model Number: CL-DCP-M11

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: Negotiable

Packaging Details: Standard Exporting Wooden Case

Delivery Time: Within 15 to 25 Work Days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 500 units per month

Get Best Price
Contact Now
Specifications
High Light:

teppanyaki table grill

,

built in teppanyaki grill

Product Name:
11 Seats Stainless Steel Electromagnetic Heating Bridge Shape Upper Or Down Fume Exhaustion Teppanyaki Grill Table
Material:
Stainless Steel And Special Alloy Steel
Heating Method:
Electromagnetic Or Induction
Main Heating Area:
Regular: 450*400mm Or Enlarged: 600*400mm
Dimension With Table Top:
3200*1900*800mm
Rated Power:
380V/50HZ/8KW Or 220V/60HZ/6KW
Product Name:
11 Seats Stainless Steel Electromagnetic Heating Bridge Shape Upper Or Down Fume Exhaustion Teppanyaki Grill Table
Material:
Stainless Steel And Special Alloy Steel
Heating Method:
Electromagnetic Or Induction
Main Heating Area:
Regular: 450*400mm Or Enlarged: 600*400mm
Dimension With Table Top:
3200*1900*800mm
Rated Power:
380V/50HZ/8KW Or 220V/60HZ/6KW
Description
Bridge Shape Upper or Down Fume Exhaustion Teppanyaki Grill Table With 11 Seats

11 Seats Stainless Steel Electromagnetic Heating Bridge Shape Upper or Down Fume Exhaustion Teppanyaki Grill Table



Amazing Craftsmanship of 11 Seats Stainless Steel Electromagnetic Heating Bridge Shape Upper or Down Fume Exhaustion Teppanyaki Grill Table



Plate Leveling
1. Remove the steel slag and burrs during cutting.
2. Leveling the plate until the evenness is no more than 0.5mm within an area of 300mm2.

Machine Processing
1. The flat plates will be planned and shaped by a planner leaving 0.3mm allowance for grinding by a grinder.
2. The non-flat plates will be cut and planned first, leaving 0.3mm allowance for grinding by a grinding wheel.
3. The processing smoothness requirement is RA0.8.

Plate Installation
1. Install according to the technical requirements in the drawing, and the parts with marks of tolerance dimensions must be left with corresponding welding shrinkage allowance to ensure the sizes after welding are within the tolerance.
2. The welding must be full penetration, and the welded surface must be smooth without solder faults, solder skips, slag inclusion, gas holes, cracks or undercut.
3. Correction after the welding temperature is reduced to make the plate evenness less than 0.2mm within 500mm², and the straightness of each edge less than 0.2mm within 500mm².

Plate Polishing
1. Grinding the uneven weld bead then polish and shape carefully. The connecting part of the plate and trim strip must be smooth without sinking.
2. Fine grinding with fine wheel with processing requirement of the smoothness RA0.8.
3. Fine polishing of the whole plate with processing requirement of the smoothness RA0.4.





Below is the technical parameters for this 11 Seats Stainless Steel Electromagnetic Heating Bridge Shape Upper or Down Fume Exhaustion Teppanyaki Grill Table

Product Name 11 Seats Stainless Steel Electromagnetic Heating Bridge Shape Upper or Down Fume Exhaustion Teppanyaki Grill Table
Heating Electromagnetic (Induction)
Material Stainless Steel & Alloy Steel
Parameter 380V/50HZ/8KW or 220V/60HZ/6KW
Cooking Area Regular: 450*400mm or Enlarged: 600*400mm
Capacity 11 Seats
Grill Dimension 2300*960*800mm
Dimension with Table Top 3200*1900*800mm
Exhaustion Built-in air blower (380V/0.25KW)
Purification Built-in electrostatic fume purifier (220V/0.25KW)
Table Decoration Regular design/customization
Application Outdoor barbecue, restaurant, hotel, food plazza, buffet car, etc.
Cookable Food Beef, mutton, chicken, fish, shellfish, vegetable, rice, noodle, etc.
Lead Time 15-30 working days
Packaging Standard Shipping Wooden Case
Brand GREENARK/OEM
Certification ISO9001-2008, CE available; CSA, UL in progress





Bridge Shape Upper or Down Fume Exhaustion Teppanyaki Grill Table With 11 Seats 0
